This article teaches you how to implement Llama3 from scratch.
Since Meta released the open-source model Llama3 series, it has outperformed industry SOTA models on several key benchmarks and has a significant lead in code generation tasks. Amazing! The top 10 open-source large models!
Since then, developers have started local deployments and implementations, such as the Chinese implementation of Llama3 and the pure NumPy implementation of Llama3.
Recently, a developer named “Nishant Aklecha” released a repository that implements Llama3 from scratch, providing very detailed explanations of the attention matrix multiplication across multiple heads, positional encoding, and each layer. The project has already received 1.5k stars on GitHub, indicating its value!
Implementing Llama3 from Scratch
Project address:
https://github.com/naklecha/llama3-from-scratch
First, load the tensors from the Llama3 model files provided by Meta.
Download link:
https://llama.meta.com/llama-downloads/
Next is the tokenizer; the author states that they do not intend to implement the tokenizer themselves and thus borrowed from Andrej Karpathy’s implementation:
from pathlib import Path
import tiktoken
from tiktoken.load import load_tiktoken_bpe
import torch
import json
import matplotlib.pyplot as plt
tokenizer_path = "Meta-Llama-3-8B/tokenizer.model"
special_tokens = [
"<|begin_of_text|>",
"<|end_of_text|>",
"<|reserved_special_token_0|>",
"<|reserved_special_token_1|>",
"<|reserved_special_token_2|>",
"<|reserved_special_token_3|>",
"<|start_header_id|>",
"<|end_header_id|>",
"<|reserved_special_token_4|>",
"<|eot_id|>", # end of turn
] + [f"<|reserved_special_token_{i}|>" for i in range (5, 256 - 5)]
mergeable_ranks = load_tiktoken_bpe (tokenizer_path)
tokenizer = tiktoken.Encoding (
name=Path (tokenizer_path).name,
pat_str=r"(?i:'s|'t|'re|'ve|'m|'ll|'d)|[^
\p {L}\p {N}]?\p {L}+|\p {N}{1,3}| ?[^
\s\p {L}\p {N}]+[\r\n]*|\s*[\r\n]+|\s+(?!\S)|\s+",
mergeable_ranks=mergeable_ranks,
special_tokens={token: len (mergeable_ranks) + i for i, token in enumerate (special_tokens)},)
tokenizer.decode (tokenizer.encode ("hello world!"))'hello world!'After completing the above steps, the next step is to read the model files. Since this study implements Llama3 from scratch, it reads one tensor file at a time.
model = torch.load ("Meta-Llama-3-8B/consolidated.00.pth")
print (json.dumps (list (model.keys ())[:20], indent=4))[
"tok_embeddings.weight",
"layers.0.attention.wq.weight",
"layers.0.attention.wk.weight",
"layers.0.attention.wv.weight",
"layers.0.attention.wo.weight",
"layers.0.feed_forward.w1.weight",
"layers.0.feed_forward.w3.weight",
"layers.0.feed_forward.w2.weight",
"layers.0.attention_norm.weight",
"layers.0.ffn_norm.weight",
"layers.1.attention.wq.weight",
"layers.1.attention.wk.weight",
"layers.1.attention.wv.weight",
"layers.1.attention.wo.weight",
"layers.1.feed_forward.w1.weight",
"layers.1.feed_forward.w3.weight",
"layers.1.feed_forward.w2.weight",
"layers.1.attention_norm.weight",
"layers.1.ffn_norm.weight",
"layers.2.attention.wq.weight"]with open ("Meta-Llama-3-8B/params.json", "r") as f:
config = json.load (f)
config{'dim': 4096, 'n_layers': 32, 'n_heads': 32, 'n_kv_heads': 8, 'vocab_size': 128256, 'multiple_of': 1024, 'ffn_dim_multiplier': 1.3, 'norm_eps': 1e-05, 'rope_theta': 500000.0}The project author uses the following configuration to infer model details:
-
The model has 32 transformer layers;
-
Each multi-head attention block has 32 heads.
dim = config ["dim"]
n_layers = config ["n_layers"]
n_heads = config ["n_heads"]
n_kv_heads = config ["n_kv_heads"]
vocab_size = config ["vocab_size"]
multiple_of = config ["multiple_of"]
ffn_dim_multiplier = config ["ffn_dim_multiplier"]
norm_eps = config ["norm_eps"]
rope_theta = torch.tensor (config ["rope_theta"])The next operation is to convert the text into tokens; here the author uses the tiktoken library (a BPE tokenizer for OpenAI models).
prompt = "the answer to the ultimate question of life, the universe, and everything is"
tokens = [128000] + tokenizer.encode (prompt)
print (tokens)
tokens = torch.tensor (tokens)
prompt_split_as_tokens = [tokenizer.decode ([token.item ()]) for token in tokens]
print (prompt_split_as_tokens)[128000, 1820, 4320, 311, 279, 17139, 3488, 315, 2324, 11, 279, 15861, 11, 323, 4395, 374, 220]['<|begin_of_text|>', 'the', ' answer', ' to', ' the', ' ultimate', ' question', ' of', ' life', ',', ' the', ' universe', ',', ' and', ' everything', ' is', ' ']Then convert the tokens into embeddings.
embedding_layer = torch.nn.Embedding (vocab_size, dim)
embedding_layer.weight.data.copy_(model ["tok_embeddings.weight"])
token_embeddings_unnormalized = embedding_layer (tokens).to (torch.bfloat16)
token_embeddings_unnormalized.shapetorch.Size ([17, 4096])Normalize the embeddings. This study uses the RMS normalization algorithm. However, after this step, the tensor shape does not change; only the values are normalized.
# def rms_norm (tensor, norm_weights):
# rms = (tensor.pow (2).mean (-1, keepdim=True) + norm_eps)**0.5
# return tensor * (norm_weights /rms)
def rms_norm (tensor, norm_weights):
return (tensor * torch.rsqrt (tensor.pow (2).mean (-1, keepdim=True) + norm_eps)) * norm_weightsBuild the first layer of the transformer. After completing the above preparations, the next step is to build the first layer of the transformer: access layer.0 (i.e., the first layer), and the normalized embedding dimension is still [17×4096].
token_embeddings = rms_norm (token_embeddings_unnormalized, model ["layers.0.attention_norm.weight"])
token_embeddings.shapetorch.Size ([17, 4096])Implement attention from scratch. Load the attention heads of the first layer of the transformer:
print (
model ["layers.0.attention.wq.weight"].shape,
model ["layers.0.attention.wk.weight"].shape,
model ["layers.0.attention.wv.weight"].shape,
model ["layers.0.attention.wo.weight"].shape)
torch.Size ([4096, 4096]) torch.Size ([1024, 4096]) torch.Size ([1024, 4096]) torch.Size ([4096, 4096])Expand queries. Expand the queries from multiple attention heads to obtain a shape of [32x128x4096], where 32 is the number of attention heads in Llama3, 128 is the size of the query vector, and 4096 is the size of the token embedding.
q_layer0 = model ["layers.0.attention.wq.weight"]
head_dim = q_layer0.shape [0] //n_heads
q_layer0 = q_layer0.view (n_heads, head_dim, dim)
q_layer0.shapetorch.Size ([32, 128, 4096])Access the query weight matrix of the first head in the first layer, which has a size of [128×4096].
q_layer0_head0 = q_layer0 [0]
q_layer0_head0.shapetorch.Size ([128, 4096])Multiply the query weights with the token embeddings to obtain the token queries; here you can see the result size is [17×128].
q_per_token = torch.matmul (token_embeddings, q_layer0_head0.T)
q_per_token.shapetorch.Size ([17, 128])Positional encoding. Now at this stage, each token in the prompt has a corresponding query vector; however, considering a single query vector, we do not know its position in the prompt. The author uses RoPE (Rotary Positional Embedding) to solve this.
q_per_token_split_into_pairs = q_per_token.float ().view (q_per_token.shape [0], -1, 2)
q_per_token_split_into_pairs.shapetorch.Size ([17, 64, 2])In the above steps, this study splits the query vectors into pairs and applies a rotation angle shift to each pair.
Use complex dot product to rotate the vectors.
zero_to_one_split_into_64_parts = torch.tensor (range (64))/64
zero_to_one_split_into_64_partstensor ([0.0000, 0.0156, 0.0312, 0.0469, 0.0625, 0.0781, 0.0938, 0.1094, 0.1250,
0.1406, 0.1562, 0.1719, 0.1875, 0.2031, 0.2188, 0.2344, 0.2500, 0.2656,
0.2812, 0.2969, 0.3125, 0.3281, 0.3438, 0.3594, 0.3750, 0.3906, 0.4062,
0.4219, 0.4375, 0.4531, 0.4688, 0.4844, 0.5000, 0.5156, 0.5312, 0.5469,
0.5625, 0.5781, 0.5938, 0.6094, 0.6250, 0.6406, 0.6562, 0.6719, 0.6875,
0.7031, 0.7188, 0.7344, 0.7500, 0.7656, 0.7812, 0.7969, 0.8125, 0.8281,
0.8438, 0.8594, 0.8750, 0.8906, 0.9062, 0.9219, 0.9375, 0.9531, 0.9688,
0.9844])freqs = 1.0 / (rope_theta ** zero_to_one_split_into_64_parts)
freqstensor ([1.0000e+00, 8.1462e-01, 6.6360e-01, 5.4058e-01, 4.4037e-01, 3.5873e-01,
2.9223e-01, 2.3805e-01, 1.9392e-01, 1.5797e-01, 1.2869e-01, 1.0483e-01,
8.5397e-02, 6.9566e-02, 5.6670e-02, 4.6164e-02, 3.7606e-02, 3.0635e-02,
2.4955e-02, 2.0329e-02, 1.6560e-02, 1.3490e-02, 1.0990e-02, 8.9523e-03,
7.2927e-03, 5.9407e-03, 4.8394e-03, 3.9423e-03, 3.2114e-03, 2.6161e-03,
2.1311e-03, 1.7360e-03, 1.4142e-03, 1.1520e-03, 9.3847e-04, 7.6450e-04,
6.2277e-04, 5.0732e-04, 4.1327e-04, 3.3666e-04, 2.7425e-04, 2.2341e-04,
1.8199e-04, 1.4825e-04, 1.2077e-04, 9.8381e-05, 8.0143e-05, 6.5286e-05,
5.3183e-05, 4.3324e-05, 3.5292e-05, 2.8750e-05, 2.3420e-05, 1.9078e-05,
1.5542e-05, 1.2660e-05, 1.0313e-05, 8.4015e-06, 6.8440e-06, 5.5752e-06,
4.5417e-06, 3.6997e-06, 3.0139e-06, 2.4551e-06])freqs_for_each_token = torch.outer (torch.arange (17), freqs)
freqs_cis = torch.polar (torch.ones_like (freqs_for_each_token), freqs_for_each_token)
freqs_cis.shape# viewing tjhe third row of freqs_cis
value = freqs_cis [3]
plt.figure ()
for i, element in enumerate (value [:17]):
plt.plot ([0, element.real], [0, element.imag], color='blue', linewidth=1, label=f"Index: {i}")
plt.annotate (f"{i}", xy=(element.real, element.imag), color='red')
plt.xlabel ('Real')
plt.ylabel ('Imaginary')
plt.title ('Plot of one row of freqs_cis')
plt.show ()
Now each token query has a complex number.
q_per_token_as_complex_numbers = torch.view_as_complex (q_per_token_split_into_pairs)
q_per_token_as_complex_numbers.shapetorch.Size ([17, 64])q_per_token_as_complex_numbers_rotated = q_per_token_as_complex_numbers * freqs_cis
q_per_token_as_complex_numbers_rotated.shapetorch.Size ([17, 64])Rotated vectors.
q_per_token_split_into_pairs_rotated = torch.view_as_real (q_per_token_as_complex_numbers_rotated)
q_per_token_split_into_pairs_rotated.shapetorch.Size ([17, 64, 2])Now there is a new query vector (rotated query vector) with a shape of [17×128], where 17 is the number of tokens, and 128 is the dimension of the query vector.
q_per_token_rotated = q_per_token_split_into_pairs_rotated.view (q_per_token.shape)
q_per_token_rotated.shapetorch.Size ([17, 128])The keys (almost the same as the queries) also generate key vectors of dimension 128. The key weights are only 1/4 of the queries because the key weights are shared across 4 heads to reduce the required computation; the keys will also be rotated to add positional information, just like the queries.
k_layer0 = model ["layers.0.attention.wk.weight"]
k_layer0 = k_layer0.view (n_kv_heads, k_layer0.shape [0] //n_kv_heads, dim)
k_layer0.shapetorch.Size ([8, 128, 4096])k_layer0_head0 = k_layer0 [0]
k_layer0_head0.shapetorch.Size ([128, 4096])k_per_token = torch.matmul (token_embeddings, k_layer0_head0.T)k_per_token.shapetorch.Size ([17, 128])k_per_token_split_into_pairs = k_per_token.float ().view (k_per_token.shape [0], -1, 2)k_per_token_split_into_pairs.shapetorch.Size ([17, 64, 2])k_per_token_as_complex_numbers = torch.view_as_complex (k_per_token_split_into_pairs)k_per_token_as_complex_numbers.shapetorch.Size ([17, 64])k_per_token_split_into_pairs_rotated = torch.view_as_real (k_per_token_as_complex_numbers * freqs_cis)k_per_token_split_into_pairs_rotated.shapetorch.Size ([17, 64, 2])k_per_token_rotated = k_per_token_split_into_pairs_rotated.view (k_per_token.shape)k_per_token_rotated.shapetorch.Size ([17, 128])The rotated values for each token query and key are as follows, with both the queries and keys now having a shape of [17×128].
The next step is to multiply the query and key matrices. The attention score matrix (qk_per_token) has a shape of [17×17], where 17 is the number of tokens in the prompt.
qk_per_token = torch.matmul (q_per_token_rotated, k_per_token_rotated.T)/(head_dim)**0.5
qk_per_token.shapetorch.Size ([17, 17])Now the query-key scores must be masked.
During the training of Llama3, the future token’s qk scores are masked. This is because during training, it only learns to predict future tokens using past tokens. Therefore, during inference, the future tokens are marked as zero.
def display_qk_heatmap (qk_per_token):
_, ax = plt.subplots ()
im = ax.imshow (qk_per_token.to (float).detach (), cmap='viridis')
ax.set_xticks (range (len (prompt_split_as_tokens)))
ax.set_yticks (range (len (prompt_split_as_tokens)))
ax.set_xticklabels (prompt_split_as_tokens)
ax.set_yticklabels (prompt_split_as_tokens)
ax.figure.colorbar (im, ax=ax)
display_qk_heatmap (qk_per_token)
mask = torch.full ((len (tokens), len (tokens)), float ("-inf"), device=tokens.device)
mask = torch.triu (mask, diagonal=1)
masktensor ([[0., -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf],
[0., 0., -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf],
[0., 0., 0., -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf],
[0., 0., 0., 0., -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf],
[0., 0., 0., 0., 0., -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf],
[0., 0., 0., 0., 0., 0., -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf],
[0., 0., 0., 0., 0., 0., 0., -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf],
[0., 0., 0., 0., 0., 0., 0., 0., -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf],
[0., 0., 0., 0., 0., 0., 0., 0., 0., -inf, -inf, -inf, -inf, -inf, -inf, -inf, -inf],
[0., 0., 0., 0., 0., 0., 0., 0., 0., 0., -inf, -inf, -inf, -inf, -inf, -inf, -inf],
[0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., -inf, -inf, -inf, -inf, -inf, -inf],
[0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., -inf, -inf, -inf, -inf, -inf],
[0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., -inf, -inf, -inf, -inf],
[0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., -inf, -inf, -inf],
[0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., -inf, -inf],
[0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., -inf],
[0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0., 0.]])qk_per_token_after_masking = qk_per_token + mask
display_qk_heatmap (qk_per_token_after_masking)
qk_per_token_after_masking_after_softmax = torch.nn.functional.softmax (qk_per_token_after_masking, dim=1).to (torch.bfloat16)
display_qk_heatmap (qk_per_token_after_masking_after_softmax)
Values (almost at the end of attention)
These scores (0-1) are used to determine how much value matrix each token uses.
-
Just like the keys, the value weights are also shared across 4 attention heads (to save computation)
-
As a result, the value weight matrix below has a shape of [8x128x4096]
v_layer0 = model ["layers.0.attention.wv.weight"]
v_layer0 = v_layer0.view (n_kv_heads, v_layer0.shape [0] //n_kv_heads, dim)
v_layer0.shapetorch.Size ([8, 128, 4096])The value weight matrix for the first head of the first layer is shown below.
v_layer0_head0 = v_layer0 [0]
v_layer0_head0.shapetorch.Size ([128, 4096])The value vectors are shown below.
Now use the value weights to obtain the attention values for each token, which has a size of [17×128], where 17 is the number of tokens in the prompt, and 128 is the dimension of each token’s value vector.
v_per_token = torch.matmul (token_embeddings, v_layer0_head0.T)v_per_token.shapetorch.Size ([17, 128])The attention is shown below.
The attention vector obtained after multiplying with each token’s value has a shape of [17*128].
qkv_attention = torch.matmul (qk_per_token_after_masking_after_softmax, v_per_token)
qkv_attention.shapetorch.Size ([17, 128])Multi-head attention and single-head attention are shown below.
Now we have the attention values for the first layer and the first head.
Next, run a loop and perform the same mathematical operations as above, but for each head in the first layer.
qkv_attention_store = []
for head in range (n_heads):
q_layer0_head = q_layer0 [head]
k_layer0_head = k_layer0 [head//4] # key weights are shared across 4 heads
v_layer0_head = v_layer0 [head//4] # value weights are shared across 4 heads
q_per_token = torch.matmul (token_embeddings, q_layer0_head.T)
k_per_token = torch.matmul (token_embeddings, k_layer0_head.T)
v_per_token = torch.matmul (token_embeddings, v_layer0_head.T)
q_per_token_split_into_pairs = q_per_token.float ().view (q_per_token.shape [0], -1, 2)
q_per_token_as_complex_numbers = torch.view_as_complex (q_per_token_split_into_pairs)
q_per_token_split_into_pairs_rotated = torch.view_as_real (q_per_token_as_complex_numbers * freqs_cis [:len (tokens)])
q_per_token_rotated = q_per_token_split_into_pairs_rotated.view (q_per_token.shape)
k_per_token_split_into_pairs = k_per_token.float ().view (k_per_token.shape [0], -1, 2)
k_per_token_as_complex_numbers = torch.view_as_complex (k_per_token_split_into_pairs)
k_per_token_split_into_pairs_rotated = torch.view_as_real (k_per_token_as_complex_numbers * freqs_cis [:len (tokens)])
k_per_token_rotated = k_per_token_split_into_pairs_rotated.view (k_per_token.shape)
qk_per_token = torch.matmul (q_per_token_rotated, k_per_token_rotated.T)/(128)**0.5
mask = torch.full ((len (tokens), len (tokens)), float ("-inf"), device=tokens.device)
mask = torch.triu (mask, diagonal=1)
qk_per_token_after_masking = qk_per_token + mask
qk_per_token_after_masking_after_softmax = torch.nn.functional.softmax (qk_per_token_after_masking, dim=1).to (torch.bfloat16)
qkv_attention = torch.matmul (qk_per_token_after_masking_after_softmax, v_per_token)
qkv_attention_store.append (qkv_attention)
len (qkv_attention_store)32
Now all 32 heads on the first layer have the qkv_attention matrix, and just before finishing, all attention scores are merged into a large matrix of size [17×4096].
stacked_qkv_attention = torch.cat (qkv_attention_store, dim=-1)
stacked_qkv_attention.shapetorch.Size ([17, 4096])The weight matrix is one of the final steps.
The last thing the attention in layer 0 does is perform multiplication with the following weight matrix.
w_layer0 = model ["layers.0.attention.wo.weight"]
w_layer0.shapetorch.Size ([4096, 4096])This is a simple linear layer, so only matrix multiplication (matmul) is performed.
embedding_delta = torch.matmul (stacked_qkv_attention, w_layer0.T)
embedding_delta.shapetorch.Size ([17, 4096])
Now, the attention values after embedding changes, and they should be added to the original token embeddings.
embedding_after_edit = token_embeddings_unnormalized + embedding_delta
embedding_after_edit.shapetorch.Size ([17, 4096])Normalize and run a feedforward neural network in the embedding delta process.
embedding_after_edit_normalized = rms_norm (embedding_after_edit, model ["layers.0.ffn_norm.weight"])
embedding_after_edit_normalized.shapetorch.Size ([17, 4096])Load the ff weights and implement the feedforward network.
Llama3 uses the SwiGLU feedforward network, which is very good at adding non-linearity when needed in the model. Currently, using this feedforward network is a very standard practice in LLMs.
w1 = model ["layers.0.feed_forward.w1.weight"]
w2 = model ["layers.0.feed_forward.w2.weight"]
w3 = model ["layers.0.feed_forward.w3.weight"]
output_after_feedforward = torch.matmul (torch.functional.F.silu (torch.matmul (embedding_after_edit_normalized, w1.T)) * torch.matmul (embedding_after_edit_normalized, w3.T), w2.T)
output_after_feedforward.shapetorch.Size ([17, 4096])Now finally, the new edited embeddings for each token after the first layer are provided, and only 31 more layers need to be processed (one for loop away).
You can imagine that this edited embedding contains all the information from the queries in the first layer. Now each layer will encode increasingly complex queries on the asked question until the resulting embedding understands everything needed for the next token.
layer_0_embedding = embedding_after_edit+output_after_feedforward
layer_0_embedding.shapetorch.Size ([17, 4096])All the things done for each layer can be completed at once.
final_embedding = token_embeddings_unnormalized
for layer in range (n_layers):
qkv_attention_store = []
layer_embedding_norm = rms_norm (final_embedding, model [f"layers.{layer}.attention_norm.weight"])
q_layer = model [f"layers.{layer}.attention.wq.weight"]
q_layer = q_layer.view (n_heads, q_layer.shape [0] //n_heads, dim)
k_layer = model [f"layers.{layer}.attention.wk.weight"]
k_layer = k_layer.view (n_kv_heads, k_layer.shape [0] //n_kv_heads, dim)
v_layer = model [f"layers.{layer}.attention.wv.weight"]
v_layer = v_layer.view (n_kv_heads, v_layer.shape [0] //n_kv_heads, dim)
w_layer = model [f"layers.{layer}.attention.wo.weight"]
for head in range (n_heads):
q_layer_head = q_layer [head]
k_layer_head = k_layer [head//4]
v_layer_head = v_layer [head//4]
q_per_token = torch.matmul (layer_embedding_norm, q_layer_head.T)
k_per_token = torch.matmul (layer_embedding_norm, k_layer_head.T)
v_per_token = torch.matmul (layer_embedding_norm, v_layer_head.T)
q_per_token_split_into_pairs = q_per_token.float ().view (q_per_token.shape [0], -1, 2)
q_per_token_as_complex_numbers = torch.view_as_complex (q_per_token_split_into_pairs)
q_per_token_split_into_pairs_rotated = torch.view_as_real (q_per_token_as_complex_numbers * freqs_cis)
q_per_token_rotated = q_per_token_split_into_pairs_rotated.view (q_per_token.shape)
k_per_token_split_into_pairs = k_per_token.float ().view (k_per_token.shape [0], -1, 2)
k_per_token_as_complex_numbers = torch.view_as_complex (k_per_token_split_into_pairs)
k_per_token_split_into_pairs_rotated = torch.view_as_real (k_per_token_as_complex_numbers * freqs_cis)
k_per_token_rotated = k_per_token_split_into_pairs_rotated.view (k_per_token.shape)
qk_per_token = torch.matmul (q_per_token_rotated, k_per_token_rotated.T)/(128)**0.5
mask = torch.full ((len (token_embeddings_unnormalized), len (token_embeddings_unnormalized)), float ("-inf"))
mask = torch.triu (mask, diagonal=1)
qk_per_token_after_masking = qk_per_token + mask
qk_per_token_after_masking_after_softmax = torch.nn.functional.softmax (qk_per_token_after_masking, dim=1).to (torch.bfloat16)
qkv_attention = torch.matmul (qk_per_token_after_masking_after_softmax, v_per_token)
qkv_attention_store.append (qkv_attention)
stacked_qkv_attention = torch.cat (qkv_attention_store, dim=-1)
w_layer = model [f"layers.{layer}.attention.wo.weight"]
embedding_delta = torch.matmul (stacked_qkv_attention, w_layer.T)
embedding_after_edit = final_embedding + embedding_delta
embedding_after_edit_normalized = rms_norm (embedding_after_edit, model [f"layers.{layer}.ffn_norm.weight"])
w1 = model [f"layers.{layer}.feed_forward.w1.weight"]
w2 = model [f"layers.{layer}.feed_forward.w2.weight"]
w3 = model [f"layers.{layer}.feed_forward.w3.weight"]
output_after_feedforward = torch.matmul (torch.functional.F.silu (torch.matmul (embedding_after_edit_normalized, w1.T)) * torch.matmul (embedding_after_edit_normalized, w3.T), w2.T)
final_embedding = embedding_after_edit+output_after_feedforward
Now we have the final embedding, which is the model’s best guess for the next token. The shape of this embedding is the same as the common token embedding [17×4096], where 17 is the number of tokens, and 4096 is the embedding dimension.
final_embedding = rms_norm (final_embedding, model ["norm.weight"])
final_embedding.shapetorch.Size ([17, 4096])Decode this embedding into token values.
Use this input decoder to convert the final embedding into a token.
model ["output.weight"].shapetorch.Size ([128256, 4096])Use the embedding of the last token to predict the next value. In this example, 42 is the answer to “What is the ultimate question of life, the universe, and everything?” According to “The Hitchhiker’s Guide to the Galaxy”, most modern LLMs will answer 42, which should validate the entire code.
logits = torch.matmul (final_embedding [-1], model ["output.weight"].T)
logits.shapetorch.Size ([128256])The model predicts token number 2983 as the next token, which is the token number for 42. Below is the final code cell.
next_token = torch.argmax (logits, dim=-1)
next_tokentensor (2983)Finally, launch.
tokenizer.decode ([next_token.item ()])'42'Editor: Yu Tengkai
Proofreader: Lin Yilin
