1

『The Original Intention of Writing This Article』

Recently, while reproducing the training code of a paper, I found that the total loss in the original paper consists of multiple losses. If there is only one loss, then you can directly use loss.backward(), but here there is more than one. At first, when I saw more than one loss, I didn’t know where to put backward().

for j in range(len(output)):
    loss += criterion(output[j], target_var)

We know that the traditional gradient backpropagation steps are as follows:

outputs = model(images)
loss = criterion(outputs,target)

optimizer.zero_grad()
loss.backward()
optimizer.step()

First, the model calculates the corresponding loss function through the input images and labels;
Then clear the previous gradientsoptimizer.zero_grad();
Perform backpropagation and calculate the current gradientloss.backward() to backpropagate and compute the current gradient;
Update network parameters based on the current gradient. Generally, a gradient is calculated for each incoming batch of data, and then the network is updatedoptimizer.step()

Now, I need to calculate the loss in a for loop, so I was wondering if I need to perform the backward() calculation in the for loop?

for j in range(len(output)):
    loss += criterion(output[j], target_var)
    loss.backward()

However, when I used the backward method after calculating a loss, I encountered an error: Pytorch – RuntimeError: Trying to backward through the graph a second time, but the buffers have already been freed. Specify retain_graph=True when calling backward the first time.

The reason is that in Pytorch, a computation graph only allows a single loss backpropagation calculation. After each gradient backpropagation, the intermediate variables are released. Therefore, if you want to calculate the graph’s gradient again in this batch, the program will find that the intermediate computation graph is gone, and naturally, it will not be able to compute the gradient.

I saw a solution online that is to add retain_grad=True in the backward, that is, backward(retain_graph=True).

This means temporarily not releasing the computation graph, so the computation graph will not be released during the subsequent training process, but will continue to accumulate. However, as training progresses, OOM may occur. Therefore, at the last loss calculation, you need to remove (retain_graph=True), that is, only use backward(), which means that only the final loss needs to release resources and compute gradients, while the previous several losses do not perform this step.

for j in range(len(output)):
    loss += criterion(output[j], target_var)
loss.backward()

Some may ask, why not write it this way? I used to do it like this, but I found that the loss did not decrease, so I started to look for reasons in the loss, but I still do not understand why it did not decrease. I hope those who understand can communicate with me~

In fact, when encountering such situations, the best way is to write them separately and then sum them into a total loss for the backward calculation. For example:

loss1= Loss(output[0], target)
loss2= Loss(output[1], target)
loss3= Loss(output[2], target)
loss4= Loss(output[3], target)

loss = loss1 + loss2 + loss3 + loss4
loss.backward()

When I wrote it this way, the loss decreased normally. Seeing that the loss was decreasing normally, I felt a bit relieved.

2

『Other Possible Reasons for Errors』

While checking the information, I found that even calculating a single loss may also lead to errors.

It is possible that you are calculating on one cpu and another on gpu, so just set the devices to be the same.
It is also possible that in multiple loops, some inputs do not require gradient calculation; at this time, you can set the input’s require_grad to False.
Regarding the require_grad attribute in tensors: If a tensor has its requires_grad=True, then calling the backward method will compute the gradient of this tensor during backpropagation. However, it is essential to note that after computing the gradient, this gradient will not necessarily be preserved in the grad attribute, only for leaf nodes with requires_grad=True will the gradient be preserved in the grad attribute. For non-leaf nodes, i.e., intermediate nodes, we generally release the calculated gradients after computing them for more efficient memory utilization.
When using LSTM and GRU networks, I think it is because they not only compute gradients from forward to backward but also backward to forward, so it can be seen as gradients propagating in both directions. During this process, there may be overlapping parts. Therefore, you may need to use detach to truncate. In the source code, the comment for detach is: Returns a new Variable, detached from the current graph. It makes a node a variable that does not require gradients, detaching it from the current computation graph. Therefore, when backpropagating through this node, the gradient will not propagate forward from this node.

`detach()` and `detach_()`

pytorch has two functions detach() and detach_()<code>, both of which have similar names and functions, used to cut off the backpropagation of gradients. So when will they be used?

When training a network, you may want to keep some network parameters unchanged while only adjusting part of the network parameters; or only train part of the branch network of the network without letting its gradients affect the main network’s gradients. At this time, we can use these two functions to truncate the backpropagation of gradients.

The difference between the two is that detach_() modifies the original tensor, while detach() generates a new tensor.

Using detach() will return a new Variable. Although it is detached from the current computation graph, it still points to the original variable’s storage location, sharing the same memory area. After using detach, its requires_grad attribute becomes False, meaning it no longer requires gradient computation. Even if you later set its requires_grad back to True, it still won’t have a gradient grad. Thus, we will continue using this new variable for computation, and during backpropagation, gradients will be computed until reaching the node that called detach(), at which point the gradient will stop propagating.

However, the returned variable and the original node share the same memory area, so if you modify it after using detach, it may lead to errors when calling backward().

Using tensor.detach_() will detach a tensor from the graph that created it and set it as a leaf node. For example:

Assuming the initial variable relationship is:x ->m -> y, then the leaf node here is x. When you perform m.detach_(), it first cancels the association between m and the previous node x, and grad_fn becomes None. At this point, the relationship becomes x, m ->y, and now m becomes a leaf node. Then, if you set the requires_grad attribute of m to False, when we perform backward() on y, it will not compute the gradient of m.

3

『How to Write a More Memory-Efficient Backward』

Speaking of gradient backpropagation, I have also seen some people’s writing online that aims to save memory:

for i, (images, target) in enumerate(train_loader):
    images = images.cuda(non_blocking=True)
    target = torch.from_numpy(np.array(target)).float().cuda(non_blocking=True)
    outputs = model(images)
    loss = criterion(outputs, target)
    loss = loss / accumulation_steps

    loss.backward()

    if (i + 1) % accumulation_steps == 0:
        optimizer.step()
        optimizer.zero_grad()

First, perform forward propagation, inputting data into the network for inference to get results
Input the predicted results and label into the loss function to compute the loss
Perform backpropagation to compute gradients
Repeat the previous steps, first without clearing gradients, but rather accumulating gradients, and when the gradients reach a fixed count, update network parameters, then set gradients to zero

Gradient accumulation means getting one batch of data each time, calculating gradients once, but not clearing them, instead accumulating gradients, and continuously accumulating until reaching a certain count, then updating network parameters and clearing gradients for the next loop.

Through this delayed parameter update method, it can achieve effects similar to using a large batch size. In my usual experimental process, I generally adopt gradient accumulation techniques, and in most cases, models trained with gradient accumulation perform significantly better than those trained with small batch sizes.

Under certain conditions, the larger the batch size, the better the training effect. Gradient accumulation effectively expands the batch size. If accumulation_steps is 8, then the batch size is effectively expanded by 8 times. When using, it is necessary to note that the learning rate should also be appropriately increased: because more samples are used, the gradients become more stable.

Some may ask, why not directly sum the multiple batch losses first and then average, followed by backpropagation and updates?

In my understanding, this is to reduce memory consumption. When summing multiple batch losses and then averaging before backpropagation, we will perform accumulation_steps forward computations, and each forward computation generates a computation graph. In other words, this approach will generate accumulation_steps computation graphs before performing backward calculations.

In contrast, using the above code, after each batch forward computation ends, it performs the backward computation, and after the computation ends, it releases the computation graph. Since the gradient calculations of both processes are accumulated, the results are the same, but the above method will generate at most one computation graph at any time, thus reducing memory consumption during computation.

4

『Conclusion』

In fact, through this discussion, I can only say that I have a slightly deeper understanding, but I still do not fully understand the principles involved. For example, the tracking of autograd, the properties of in-place operations, when requires_grad is True, when it is False, when gradients will be overwritten, etc., I am still confused. Especially the writing method above, I do not understand why the loss suddenly decreased, so I still need to learn and practice more to remember and understand deeply.

I have also seen many articles mention: in fact, most of the writing methods are very efficient, so unless under very heavy memory pressure, one generally will not use too many complicated operations.

The author is not very knowledgeable, if there are any errors in the above content, please feel free to point them out, and I look forward to communicating and discussing with everyone. Thank you!
