As the industrial application of machine learning continues to develop, understanding, explaining, and defining how machine learning models work seems to be an increasingly obvious trend. For non-deep learning type machine learning classification problems, XGBoost is the most popular library. Because XGBoost scales well to large datasets and supports multiple languages, it is particularly useful in commercial environments. For example, using XGBoost, it is easy to train models in Python and deploy them in a Java product environment.

Although XGBoost can achieve high accuracy, the process of how XGBoost makes decisions to achieve such high accuracy is still not transparent enough. This lack of transparency can be a serious flaw when directly handing results to clients. Understanding why things happen is very useful. Companies that turn to apply machine learning to understand data also need to understand the predictions made by the model. This has become increasingly important. For example, no one wants a credit institution to use a machine learning model to predict a user’s creditworthiness without being able to explain the process behind those predictions.

Another example is if our machine learning model says that a marriage record and a birth record are related to the same person (record association task), but the dates on the records suggest that one party in the marriage is very old and the other is very young, we might question why the model associates them. In such cases, understanding why the model made such predictions is very valuable. The result may be that the model considered the uniqueness of names and locations and made the correct prediction. But it may also be that the model’s features did not properly account for the age gap on the records. In this case, understanding the model’s predictions can help us find ways to improve model performance.

In this article, we will introduce some techniques to better understand the prediction process of XGBoost. This allows us to leverage the power of gradient boosting while still understanding the model’s decision-making process.

To explain these techniques, we will use the Titanic dataset. This dataset contains information about each Titanic passenger (including whether they survived). Our goal is to predict whether a passenger survived and understand the process behind that prediction. Even using this data, we can see the importance of understanding model decisions. Imagine if we had a dataset of passengers from a recent shipwreck. The purpose of building such a predictive model is not actually to predict the outcome itself, but understanding the prediction process can help us learn how to maximize survivors in the event of an accident.

import pandas as pd
from xgboost import XGBClassifier
from sklearn.model_selection import train_test_split
from sklearn.metrics import accuracy_score
import operator
import matplotlib.pyplot as plt
import seaborn as sns
import lime.lime_tabular
from sklearn.pipeline import Pipeline
from sklearn.preprocessing import Imputer
import numpy as np
from sklearn.grid_search import GridSearchCV
%matplotlib inline

The first thing we need to do is observe our data, which you can find on Kaggle (https://www.kaggle.com/c/titanic/data). After obtaining the dataset, we will perform some simple cleaning. That is:

• Remove names and passenger IDs;
• Convert categorical variables to dummy variables;

• Fill and remove data using the median.

These cleaning techniques are very simple; the goal of this article is not to discuss data cleaning but to explain XGBoost, so these are quick and reasonable cleanings to prepare the model for training.

data = pd.read_csv("./data/titantic/train.csv")
y = data.Survived
X = data.drop(["Survived", "Name", "PassengerId"], 1)
X = pd.get_dummies(X)

Now let’s split the dataset into training and testing sets.

X_train, X_test, y_train, y_test = train_test_split(      X, y, test_size=0.33, random_state=42)

And build a training pipeline with a few hyperparameter tests.

pipeline = Pipeline(    [('imputer', Imputer(strategy='median')),      ('model', XGBClassifier())])     parameters = dict(model__max_depth=[3, 5, 7],                  model__learning_rate=[.01, .1],                  model__n_estimators=[100, 500])
cv = GridSearchCV(pipeline, param_grid=parameters)
cv.fit(X_train, y_train)

test_predictions = cv.predict(X_test)
print("Test Accuracy: {}".format(      accuracy_score(y_test, test_predictions)))      Test Accuracy: 0.8101694915254237

So far, we have achieved a decent accuracy, ranking in the top 500 among about 9000 competitors on Kaggle. Therefore, we still have room for further improvement, but we will leave that as an exercise for the reader.

We continue the discussion on understanding what the model has learned. A common method is to use the feature importance provided by XGBoost. The higher the level of feature importance, the greater the contribution of that feature to improving the model’s predictions. Next, we will rank the features using the importance parameter and compare their relative importance.

fi = list(zip(X.columns, cv.best_estimator_.named_steps['model'].feature_importances_))
fi.sort(key = operator.itemgetter(1), reverse=True)
top_10 = fi[:10]
x = [x[0] for x in top_10]
y = [x[1] for x in top_10]
top_10_chart = sns.barplot(x, y)
plt.setp(top_10_chart.get_xticklabels(), rotation=90)

From the above chart, it can be seen that fare and age are very important features. We can further examine the distribution of survival/death related to fare:

sns.barplot(y_train, X_train['Fare'])

We can clearly see that survivors have a much higher average fare compared to non-survivors, so it may be reasonable to consider fare as an important feature.

Feature importance may be a good way to understand general feature importance. If an exception arises, such as the model predicting that a passenger with a high fare will not survive, we can conclude that a high fare does not necessarily lead to survival. Next, we will analyze other features that may lead the model to conclude that this passenger will not survive.

This individual-level analysis can be very useful for production machine learning systems. Consider other examples, like using the model to predict whether someone can obtain a loan. We know that credit score will be an important feature in the model, but if a customer with a high credit score is rejected by the model, how do we explain that to the customer? And how do we explain it to management?

Fortunately, there has been recent research from the University of Washington on explaining the prediction process of any classifier. Their method, called LIME, has been open-sourced on GitHub (https://github.com/marcotcr/lime). This article does not intend to discuss it in depth; please refer to the paper (https://arxiv.org/pdf/1602.04938.pdf).

Next, we will attempt to apply LIME in the model. Essentially, we first need to define an interpreter that processes the training data (we need to ensure that the training dataset passed to the interpreter is exactly the dataset that will be trained):

X_train_imputed = cv.best_estimator_.named_steps['imputer'].transform(X_train)
explainer = lime.lime_tabular.LimeTabularExplainer(X_train_imputed,     feature_names=X_train.columns.tolist(),    class_names=["Not Survived", "Survived"],    discretize_continuous=True)

Then you must define a function that takes a feature array as input and returns an array with the probabilities for each class:

model = cv.best_estimator_.named_steps['model']
def xgb_prediction(X_array_in):    if len(X_array_in.shape) < 2:        X_array_in = np.expand_dims(X_array_in, 0)    return model.predict_proba(X_array_in)

Finally, we pass an example for the interpreter to use your function to output the feature numbers and labels:

X_test_imputed = cv.best_estimator_.named_steps['imputer'].transform(X_test)
exp = explainer.explain_instance(      X_test_imputed[1],       xgb_prediction,       num_features=5,       top_labels=1)
exp.show_in_notebook(show_table=True,                      show_all=False)

Here we have an example where there is a 76% chance of not surviving. We also want to see which features contribute the most to which class and how important they are. For instance, when Sex = Female, the chances of survival are higher. Let’s take a look at the bar chart:

sns.barplot(X_train['Sex_female'], y_train)

sns.barplot(X_train['Pclass'], y_train)

It appears that the survival rate for Pclass equal to 2 is still quite low, so we have gained more understanding of our prediction results. Looking at the top 5 features displayed by LIME, it seems that this person should still have survived; let’s check their label:

y_test.values[0]>>>1

This person did survive, so our model was wrong! Thanks to LIME, we have some insights into the cause of the problem: it seems that Pclass may need to be discarded. This approach can help us find ways to improve the model.

This article provides readers with a simple and effective way to understand XGBoost. We hope these methods can help you make reasonable use of XGBoost and enable your models to make better inferences.
